CG-450 High–Shear Colloidal Series

For more information and pricing
Request Quote


Download Specification

The ChemGrout CG-450/2L4 are specially designed, skid or wheel mounted, high shear colloidal injection systems designed for vacuum grouting of post tensioned cables ducts or small injection projects. These units are designed to inject PT Cable grouts for small tendons or voids. Materials include Sika 300 PT, MBT 1205 and a wide variety of other PT grouts. This unit features a 20-gallon (76 liters) high shear colloidal mixing tank, a 2L4 progressing cavity pump,and a 34 gal (128 liter) agitator tank. The mixing tank is equipped with a baffle and a variable speed high-shear impeller, rotating at speeds up to 3000 rpm, providing rapid mixing action. From the mix tank, material flows through a large 4” slide valve, onto a fine mesh screen, and into the agitator tank. The injection pump is a variable speed, positive displacement, progressing cavity pump that delivers up to 6 gpm, 174 psi (22 lpm, 12 bar). This unit can be powered by compressed air, electric/hydraulic, gas/hydraulic or diesel/hydraulic. The rugged steel frame, complete with caster type wheel stands up to the toughest conditions on the job site. All moving parts are covered for safety. Operator controls are centrally located for efficient production.

How to Find the Right Equipment

Use the ChemGrout Pumpability Index®

Match your project’s grout materials to the correct ChemGrout pump for reliable results.

Quickly compare grout compatibility across different pre-blended manufacturers and identify the right ChemGrout pump for each material.

Match grout materials to the minimum pump size required for each jobsite application, ensuring reliable performance and efficient results.
